80kW High Power Water Cooled Thermal Sensors

Product Features

1.Continuous Laser Power Measurement:

Our system offers seamless monitoring of laser power, capable of handling up to 80kW.

2.Patented Beam Expansion Design:

Our exclusive two-dimensional beam expansion technology significantly reduces power density, enhancing the performance and safety of your laser operations.

3.Reflective Cone-Free Design:

This innovative feature minimizes the risk of laser-induced damage, thereby improving overall reliability and system stability.

4.High Linearity:

Our device boasts exceptional linearity, eliminating the need for time-consuming sectional calibration processes.

5.Exceptional Cavity Absorption:

With an absorption rate of up to 99.86%, our system ensures minimal backscattered power at just 0.14%, for optimal efficiency.

6.Generous Aperture Size:

The 86mm aperture allows for a wider range of applications and increased flexibility in your laser operations.

Dimensions

Product Specifications

Notes:

(a)Time from zero to 95% of stable  value is 40-60s;

(b).Recommended laser diameter>50mm@80kW;

(c).Recommended water temperature range:18-30°C;water temperature change rate:<1℃/min.

Product Images

FAQ

1.Payment Methods:

Q: What payment methods do you accept?

A: We accept several different payment methods, including T/T (bank transfer), credit card, PayPal, and Western Union.

Q: Can I pay with my credit card?

A: Yes, we accept most major credit cards for payment. We will create a payment link through our online business platform alibaba.com. It could be fast and convenient.

2.Shipping Methods:

Q: What shipping methods do you offer?

A: We offer several different shipping methods, including UPS, TNT, FedEx, DHL, sea shipment, and air shipment.

Q: How long does it take for my order to ship?

A: The processing time for your order may vary depending on the product and shipping method selected. Once your order has been processed, we will provide you with an estimated delivery date.

Q: Can I track my shipment?

A: Yes, we will provide you with a tracking number once your order has shipped so you can track its progress.

3.After-Sales Services:

Q: What kind of after-sales services do you provide?

A: We offer a one-year warranty on all our products. If you encounter any issues or problems with your purchase, our dedicated team will assist you in resolving them promptly and positively.

Q: How can I request after-sales support?

A: If you need assistance with your product or have any questions regarding the warranty, please reach out to our customer support team. They can be contacted via email or phone during our business hours.
