Product ID: BND-IP56X
IP Rating:IP5X IP6X
Origin: China
Product description:Dust-protected enclosures to numeral 5 (IP5X) allow a limited quantity of dust to penetrate under certain conditions.
Dust-tight enclosures to numeral 6(IP6X) do not allow any dust to penetrate.
The sand and dust testing chamber aims to evaluate the product's resistance to dust particles.
Sand and dust testing is typically an IP Ingress Protection test. All sand and dust tests are designed to test a component's resistance to a dust environment. Sand and dust create a harsh environment for automotive chassis, under-hood, and exterior mounted devices.
Product Features
1. For both IP5X and IP6X dustproof testing.
2. The enclosure is made of steel plate and the surface is painted with baking varnish, rust-proof and durable.
3. The inner box and the sample holder are made of stainless steel plates to ensure no rust for long time use.
4. Large transparent observation window and LED lighting inside for easier observation.
5. Dust-removable device at the bottom of the device, which can easily replace the used dust 100%.
6. A special device to prevent the dusut from sticking to the wall of inner box.
7. There is an air suction pipe in the box, which can complete the vacuuming action on the sample (requires the sample to reserve the air hole position).
8. Sand dust test box control system: 7-inch touch screen + Panasonic PLC
9. Heating system: The circulating air duct is equipped with a heater to warm the dust to avoid dust condensation.
10. Vacuum system: equipped with vacuum pump, vacuum pressure, air filtration, flow meter, pressure regulating triple piece, connecting pipe.
11. All specifications are fully in accordance with IEC60529.
12. ISO 17025 / ILAC calibration certificate available. (with extra cost)
Reference
According to IEC60529: Degrees of protection provided by enclosures(IP Code)
Dust test for first characteristic numerals 5 (Dust chamber figure 2, with or without underpressure) and 6 (Dust chamber figure 2, with underpressure)
IEC60529 Figure 2 – Test device to verify protection against dust (dust chamber)
( Bottom of our dust chamber BND-IP56X)
Calibration Certificate
* Tips for calibration
1. This is ISO 17025 / ILAC calibration certificate issued by third party lab.
2. It is with extra cost and takes around 7 work days for calibration.
3. Suggested recalibration interval is one year.
4. One item for one certificate and the name and address of your company will be indicated in the cover.
Product Parameters
No. | Item | BND-IP56X -125L | BND-IP56X -500L | BND-IP56X -1000L | BND-IP56X -1500L |
1 | Inner size | 500*500*500 | 800*800*800 | 1000*1000*1000 | 1000*1500*1000 |
2 | Outer Size | L950×D720×H1500 | L1250×D1020×H1770 | L1450×D1220×H1970 | L1450*D1720*H1970 |
3 | temperature range | RT+10~70℃(Clarify when order) | |||
4 | relative humidity | 45%~75%（Can't display） | |||
5 | Standard line warp of metal screen | 50um | |||
6 | Standard spacing between lines | 75um | |||
7 | Dosage of talc powder | 2～4kg/m | |||
8 | Test Dust | Dry talc powder | |||
9 | Powder spraying Method | Free Dust Falling | |||
10 | Total Test Time | 0-999999 min Adjustable | |||
11 | Vibration time | 0-999999s Adjustable | |||
12 | Timing accuracy | ±1 second | |||
13 | Outer case material | A3 Electrostatic Spraying Steel Plate | |||
14 | Inner case material | SUS304 SS | |||
15 | Door structure | Large observation windows and dust scrapers are provided on the door of the box. | |||
16 | Protector | 0-999 Hours Adjustable | |||
vacuum degree | -4kPa-0（Adjustable） | ||||
Pumping speed | 0-2400L/Hour（Adjustable） | 0-4800 L/Hour（Adjustable) | 0-6000 L/Hour（Adjustable） | ||
17 | Power Supply (V) | AC220V | |||
18 | Power（KW） | 1KW | 1.5KW | 2KW | |
19 | Test Standard | IEC60529（IP5X、IP6X) | |||
Product Images
(Dust chamber color: blue+white)
(Dust chamber color: white)
（Larger size of dust chamber with 2 doors）
( Dustproof socket inside the chamber, which is avaible to supply power to the sample)
( LED lighting inside for easier observation)
(Inner of dust chamber)
(Packed by solid plywood case to avoid damages during transportation.)
